fuel guages & dipsticks

Glass or plastic fuel sight tube gauges can easily be damaged by knocks or theheat from a fire and can therefore only be used on diesel tanks. Where they are used they must be fitted with self-closing valves at the top and bottom (or bottom only, if the top connection is on the upper surface of the tank), and must be protected against damage, e.g. by use of a cage, by design, or by position. If your fuel tank is fitted with a permanent dipstick arrangement it must be vapour-tight to prevent fuel or vapour leaking into the boat.

Damage can be caused to the bottom of your boat's fuel tank(s) if you allow a portable dipstick to strike it. This could eventually lead to a fuel leak. To prevent this from happening it's recommended that you fit a cross pin arrangement,wider than the fuel filling connection, to the dipstick. [2.8]
